OceanAire PAC3632 – 36,050 BTU/h – 3 ton air-cooled – 208-230V/3 Ph

$5,460.00

A great choice for Backup Cooling for computer rooms and offices on nights and weekends

The OceanAire PAC3632 is designed to direct cool air to specific areas through a supply air grill located on the upper front of the unit while exhausting discharge heat from the top of the unit.   This model is ideal for situations where central AC systems are turned off over the weekend and critical areas require supplemental cooling.

Housed in a sturdy gray polyester powder-coated 18-gauge sheet metal cabinet, it uses 208-230V/3 Phase power.  A dedicated circuit and time-delay fuses/circuit breakers are recommended.

Set the thermostat at the “start” and “stop” temperatures you want and the machine will do the rest.

A 5-gallon condensate tank is standard (pump optional).  Accessories include an exhaust duct kit, nozzle kits, and more.

Standard features include:

  • Amps: 17.2
  • Voltage: 208-230V/3 Phase
  • 24V control circuit with non–programmable electronic thermostat
  • Washable electrostatic air filter
  • Swivel ball bearing casters (Front locks)
  • 2-speed fan switch
  • 5-gal. condensate tank
  • Condensate tank alert light
  • 10-ft. LCDI power cord
  • High-pressure safety switch
  • Three-phase power indicator light
  • 50 ¼” H x 27 ½” W x 35” D
  • Net Wt 365 lb.

Cooling Ambient Operating range is 65ºF TO 105ºF

Not Approved for Outdoor Use

This machine is also available in 1PH (PAC3612) and 460V/3PH (PAC3634) configurations.

Specification Sheet CONTACT US for Rental Quote
