MovinCool Climate Pro X14 – 13,200 BTU/h – 1.1 ton air-cooled

$3,803.00 $3,729.00

Small but mighty spot cooling for factory and warehouse

Taking a mere 4.4 sq. ft. of floor space, the MovinCool Climate Pro X14 commercial cooler keeps people comfortable and productive with 13,200 BTU/h of cooling.

APPLICATIONS

Emergency Preparedness: When your main HVAC system goes out, rely on MovinCool to provide

continuous cooling relief to patients and staff ? or protect heat-sensitive equipment from malfunctioning or

shutting down.

Supplemental: When an emergency room or workspace gets hot or overcrowded, or a computer room or other imaging center

needs additional cooling to keep running smoothly, wheel in MovinCool to quickly bring things under control.

Permanent: For areas, your main HVAC system does not reach or is inadequate, or to provide cooling to heat-sensitive equipment during cold-weather months when the main HVAC is switched to heating mode, MovinCool is a flexible, cost-effective solution.

  • Programmable electronics for automatic operation after hours and on weekends.
  • Wireless connectivity-ready for remote monitoring and e-notifications of performance.
  • Quick-connect nozzle for simple, time-saving setup.
  • Frugal with power. Runs on 115V with 15 amp circuit ? uses just 1.3 kW.
  • Extensive cooling reach.
  • Provides effective temperature control in conditions from 70? to 113?F.

Specification Sheet Operation Manual Service Manual

Categories: , SKU: PAG-x14-020620-01
Brands:

Description

Accessories Diagram

Accessories are not included with the unit.

#

Part Num

Item

Description

1 481170-0450 Supply Air Flange Kit, 5-in dia. 5-in diameter white metal flange with wire clamp and mounting screws. Use with supply air ducts.
3 484209-0500 Dual Duct, 5-in dia. 5-in diameter white plastic flange with two 4-in nozzles that extend to 2 feet in length.
4 481744-0091 Self-Supported Duct, 5-in dia. 5-in diameter, white plastic duct that extends from 6.5 to 10 feet in length.
5 481851-0200 Trim Ring, 5-in dia. 5-in diameter black plastic ring mounts as end caps for extension duct.
6 481769-0310 Nozzle Adapter Kit, 5-in dia. Adapter converts airflow to air ducts.
8 LAY45771-0060 Flexible Air Duct, 12-in dia. (not shown) 12-in diameter wire-reinforced, accordion-style duct in 10-ft length for outdoor air exhaust. Includes clamp.
9 LA146373-8280 Celling Tile Kit, 12-in hole, plastic 24-in x 24-in plastic white tile with 12-in hole for exhaust air self-supported duct.
9 484490-1030 Celling Tile Kit, 12-in hole, metal 24-in x 24-in sheet metal tile with 12-in hole and built-in flange for exhaust air flexible duct kit
10 484350-1160 Outdoor Air Plenum White plastic plenum for return air to condenser. Hinged for filter cleaning.
11 484789-0210 Condensate Pump Kit, 110V 115V pump kit includes 3/8-in diameter x 20-ft length hose. Includes installation hardware. Maximum lift: 20 feet at 115V

Specfications

Electronic Features

Control Panel Programmable
Thermostat Control Electronic

Cooling Capacity

Rating Conditions: 95?F @ 60% RH 13,200 Btu/h

Electrical Characteristics

Voltage Requirement 1 Phase, 115 V
Total Power Consumption 1.3 kW
Current Consumption 11.5 amps
Recommended Fuse Size 15 amps
NEMA Plug Configuration 5-15P
Min. – Max. Voltage 104 – 127 V

Fans

Motor Output 0.23 kW

Evaporator

Fan Type Centrifugal
Max. Air Flow – High/Mid/Low 440/410/385 CFM
Max External Static Pressure 0.31 IWG

Condenser

Fan Type Centrifugal
Max Air Flow – High/Mid/Low 830/770/720 CFM
Max. External Static Pressure 0.19 IWG

Compressor

Type Hermetic Rotary
Output 0.75 kW

Refrigerant

Type R-410A

Dimensions

W x D x H 22 x 29 x 48 in

Weight

Net / Shipping 165 / 205 lb

Power Cord

Gauge 14 AWG (3 -core)
Length 10 ft

Condensate Tank

Capacity 5 gal

Operating Conditions

Min. – Max. @ 50% RH 70? – 113?F

Max. Duct Length

Per Cold Duct Hose 30 ft
Hot Duct Hose 60 ft

Max. Sound Level

With Condenser Duct – High/Mid/Low 57/56/55 dB(A)
Without Condenser Duct – High/Mid/Low 60/59/58 dB(A)

Additional information

Weight 165 lbs
Dimensions 22 × 29 × 48 in
